Muir HR700 / HFF700 Compact Horizontal Windlass

• HR700 Power Up / Power Down, with manual release
• Rope chain combination gypsy for rope & chain combination or chain only
• Rope Chain Management System (RCMS)
• Heavy duty dual direction motor in 12 Vdc & 24 Vdc
• Durable marine grade white gloss finish alloy housing
• Fully enclosed motor & gearbox
• Independent gypsy and capstan operation
• Luxury chromed marine grade bronze running gear
• Stainless steel drive shaft
• Cone clutch / brake
• Stainless steel mounting studs
• Shaft seal
• Clutch release handle
• Installation/Operation booklet

Vessel Length

8 – 11 m (26 – 35 ft)

Power Supply

12 Vdc

Motor

600 W

Max Load

318 kg (700 lb)

Work Load

57 kg (125 lb)

Max Line Speed

25 m / min (80 ft / min)

Chain Size

6 – 8 mm (1/4 – 5/16)

Rope Size

12 – 14 mm (1/2 – 9/16

Net Weight

12 kg (26 lb)
